SPECIFICATIONS
Rated Line Pull 11000lb (4990kg)
Motor - Series Wound (12V) 4.9kW/6.5HP
Gear Train Full Steel 3 Stage Planetary
Gear Ratio 230:1
Brake Automatic Load Holding Screw Cone
Synthetic Rope 11mm x 26.5m
Drum Size 63mm x 223m
Mounting Bolt Pattern 254mm x 114.3mm
Overall Dimensions 540mm x 163mm x 221mm
Remote Control 3.7m Handheld Remote/Wireless Remote
Battery Leads Included. 2 x 1.8m Heavy Duty Leads
Finish Black Powder Coat
Net Weight 31.4kg
Gross Weight 33.4kg (includes packaging)
Warranty Limited Lifetime
Package includes:
- Winch with Dyneema Winch Rope
- 600A Solenoid Pack with 32mm2 cables
- 3.6m Handheld Remote
- Wireless Remote
- Aluminium Hawse Fairlead
- Clevis Style Safety Hook
- Mounting Bolts
- Snatch Block
- Winch Cover
| SKU | 11XP-12VD-BLACK |
| Shipping Weight | 35.0000kg |
| Shipping Width | 0.320m |
| Shipping Height | 0.320m |
| Shipping Length | 0.635m |
| Shipping Cubic | 0.065024m3 |
Calculated shipping price at checkout is for Metro Brisbane, Sydney, Melbourne, Adelaide, Hobart, and Perth. If you are out of these areas either contact us for freight quote or we will call you prior to shipping for the extra charge
Limited Life time mechanical, 5 year electrical
